SCHNEIDER 140ATI03000

分类:
  • 发货速度快: 我们拥有专业的仓储和物流团队,能够保证您的订单快速发货
  • 品质保证: 我们所有产品均经过严格检验,确保品质优良
  • 售后服务完善: 我们提供完善的售后服务,一年质保

描述

SCHNEIDER 140ATI03000

施耐德140ATI03000是一款功能强大的模拟量输入模块,设计用于工业自动化控制系统。它能够接收来自传感器或其他模拟信号源的信号,并将其转换为数字数据供控制系统使用。

规格

  • 输入数量:8个模拟量输入
  • 功耗:1.5W
  • 地址需求:10个输入字
  • 模拟量输入分辨率:16位
  • 模拟量输入类型:支持多种热电偶类型,如S、R、T、K、E和J
  • 绝对准确度误差:根据热电偶类型,范围在+/- 4 ℃加 + 0.1% 读数至+/- 2 ℃加 + 0.1% 读数之间
  • 线性度误差:根据温度范围,误差范围在1 ℃至0.1 ℃之间
  • 温度偏移精度:0.15 μV/℃ + 0.0015% 读数/℃
  • 最大低电压等级共模抑制:>= 120 dB 50/60Hz
  • 需求总线电流:280mA



作用特征

施耐德140ATI03000模拟量输入模块具有高精度、高可靠性以及良好的适应性等特点。它能够准确接收并处理模拟信号,为控制系统提供可靠的数据支持。同时,其支持多种热电偶类型,使得模块能够适应不同的应用环境和需求。

应用领域

施耐德140ATI03000模拟量输入模块广泛应用于工业自动化、过程控制、环境监测等领域,特别是在需要高精度温度测量的场合,如医疗卫生、食品、化工、石油和电子等行业中,具有广泛的应用前景

The Schneider 140ATI03000 is a powerful analog input module designed for industrial automation control systems. It is capable of receiving signals from sensors or other analog signal sources and converting them into digital data for use by the control system.

Specifications

  • Number of Inputs: 8 analog inputs
  • Power Consumption: 1.5W
  • Address Requirement: 10 input words
  • Analog Input Resolution: 16-bit
  • Analog Input Types: Supports multiple thermocouple types such as S, R, T, K, E, and J
  • Absolute Accuracy Error: Ranges from +/- 4 ℃ plus + 0.1% of the reading to +/- 2 ℃ plus + 0.1% of the reading, depending on the thermocouple type
  • Linearity Error: Ranges from 1 ℃ to 0.1 ℃, depending on the temperature range
  • Temperature Offset Accuracy: 0.15 μV/℃ + 0.0015% of the reading/℃
  • Maximum Low-Voltage Common-Mode Rejection: >= 120 dB 50/60Hz
  • Required Bus Current: 280mA

Functional Characteristics

The Schneider 140ATI03000 analog input module features high precision, high reliability, and excellent adaptability. It accurately receives and processes analog signals, providing reliable data support for the control system. Additionally, its support for multiple thermocouple types allows it to adapt to different application environments and requirements.

Application Fields

The Schneider 140ATI03000 analog input module is widely used in industrial automation, process control, environmental monitoring, and other fields. Its high-precision temperature measurement capabilities make it particularly suitable for applications in the healthcare, food, chemical, oil, and electronics industries, among others
