SCXI-1302 NI

SCXI-1302是National Instruments(NI)生产的一款端子模块,专为模块化测量系统而设计。该模块用于连接和接线测量信号,如传感器、信号源和其他设备的信号引线,以便进行数据采集、测试和控制。

规格

  • 信号连接:提供多个信号连接端口,用于连接测量信号、电压、电流等
  • 输入通道:最多32路单端或16路差分
  • 电压范围:±10v
  • 采样速率:最高可达1ms/s
  • 分辨率:16位
  • 接口类型:USB、以太网、GPIB
  • 尺寸:3U,半机架宽度
  • 电源要求:100v ~ 240v AC, 50hz / 60hz
  • 工作温度:0 ~ 55℃
分类:
  • 发货速度快: 我们拥有专业的仓储和物流团队,能够保证您的订单快速发货
  • 品质保证: 我们所有产品均经过严格检验,确保品质优良
  • 售后服务完善: 我们提供完善的售后服务,一年质保

描述

SCXI-1302 NI

SCXI-1302是National Instruments(NI)生产的一款端子模块,专为模块化测量系统而设计。该模块用于连接和接线测量信号,如传感器、信号源和其他设备的信号引线,以便进行数据采集、测试和控制。

规格

  • 信号连接:提供多个信号连接端口,用于连接测量信号、电压、电流等
  • 输入通道:最多32路单端或16路差分
  • 电压范围:±10v
  • 采样速率:最高可达1ms/s
  • 分辨率:16位
  • 接口类型:USB、以太网、GPIB
  • 尺寸:3U,半机架宽度
  • 电源要求:100v ~ 240v AC, 50hz / 60hz
  • 工作温度:0 ~ 55℃

作用特征

  • 模块化设计:简化信号连接和配置过程,方便用户接线
  • 多路复用功能:允许将多个输入信号连接到单个采集通道上,实现不同信号之间的切换
  • 稳定性和可靠性:配备适配器和连接器,确保信号连接的稳定性和可靠性
  • 快速、可靠的信号连接:采用屏蔽设计,确保信号连接的快速性和可靠性

应用领域

  • 实验室测试:用于科学研究和实验室测试环境中,支持各种测量任务
  • 数据采集:在数据采集系统中,用于收集和处理来自不同设备和传感器的信号
  • 传感器测量:配合传感器使用,实现精准的信号测量和监控
  • 自动化控制:在工业自动化系统中,用于信号传递和控制操作

The SCXI-1302 is a terminal module manufactured by National Instruments (NI) specifically designed for modular measurement systems. This module is used to connect and wire measurement signals, such as signal leads from sensors, signal sources, and other devices, for data acquisition, testing, and control

Specifications:

  • Signal Connection: Provides multiple signal connection ports for connecting measurement signals, voltages, currents, and more
  • Input Channels: Up to 32 single-ended or 16 differential
  • Voltage Range: ±10v
  • Sampling Rate: Up to 1ms/s
  • Resolution: 16-bit
  • Interface Types: USB, Ethernet, GPIB
  • Dimensions: 3U, half-rack width
  • Power Requirements: 100v ~ 240v AC, 50hz / 60hz
  • Operating Temperature: 0 ~ 55℃

Functional Characteristics:

  • Modular Design: Simplifies signal connection and configuration processes, facilitating user wiring
  • Multiplexer Capability: Allows multiple input signals to be connected to a single acquisition channel, enabling switching between different signals
  • Stability and Reliability: Equipped with adapters and connectors to ensure stable and reliable signal connections
  • Fast and Reliable Signal Connection: Features shielded design for rapid and reliable signal connections

Application Fields:

  • Laboratory Testing: Used in scientific research and laboratory testing environments to support various measurement tasks
  • Data Acquisition: Employed in data acquisition systems for collecting and processing signals from different devices and sensors
  • Sensor Measurement: Works in conjunction with sensors for precise signal measurement and monitoring
  • Automation Control: Used in industrial automation systems for signal transmission and control operations
