SR469-P5-HI-A20-E GE

SR469-P5-HI-A20-E GE是一款电机管理继电器,专为中压电机设计,提供集成的管理和保护功能。它设计有5安培相CT二次绕组,可以监测电机的运行状态,并对电机进行过载保护、缺相保护、不平衡保护等,从而确保电机的安全运行。此外,这款继电器具有可编程的控制逻辑,可根据不同电机的保护需求进行灵活配置。

规格
SR469-P5-HI-A20-E GE提供70-265 VAC和90-300 VDC的控制电源。它还具有增强型前面板,包括一个RS-232程序端口接口,具有9600波特率,可编程至最高19200波特率。前面板设计精良,带有大LCD显示屏,可显示40个字符,方便用户查看跳闸或报警等诊断消息。

分类:
  • 发货速度快: 我们拥有专业的仓储和物流团队,能够保证您的订单快速发货
  • 品质保证: 我们所有产品均经过严格检验,确保品质优良
  • 售后服务完善: 我们提供完善的售后服务,一年质保

描述

SR469-P5-HI-A20-E GE

SR469-P5-HI-A20-E GE是一款电机管理继电器,专为中压电机设计,提供集成的管理和保护功能。它设计有5安培相CT二次绕组,可以监测电机的运行状态,并对电机进行过载保护、缺相保护、不平衡保护等,从而确保电机的安全运行。此外,这款继电器具有可编程的控制逻辑,可根据不同电机的保护需求进行灵活配置。

规格
SR469-P5-HI-A20-E GE提供70-265 VAC和90-300 VDC的控制电源。它还具有增强型前面板,包括一个RS-232程序端口接口,具有9600波特率,可编程至最高19200波特率。前面板设计精良,带有大LCD显示屏,可显示40个字符,方便用户查看跳闸或报警等诊断消息。



作用特征

  1. 集成管理与保护:集成多种保护功能,确保电机在各种运行条件下都能安全稳定地工作。
  2. 模块化设计:方便用户进行安装、维护和扩展其他功能。
  3. 多种报警功能:及时发现电机故障并提醒工作人员处理。
  4. 可编程控制:满足不同电机的保护需求,提供灵活的配置选项。

应用领域
SR469-P5-HI-A20-E GE电机管理继电器适用于大中型电机的保护和控制,广泛应用于电力、能源、工业等领域,特别是在需要高可靠性和高性能电机管理的场合。

The SR469-P5-HI-A20-E GE is a motor management relay specifically designed for medium-voltage motors, providing integrated management and protection functions. With a 5-ampere phase CT secondary winding, it monitors the motor’s operating status and performs overload protection, phase loss protection, imbalance protection, and more, ensuring the safe operation of the motor. Additionally, this relay features programmable control logic, allowing for flexible configuration based on different motor protection needs.

Specifications:
The SR469-P5-HI-A20-E GE offers control power ranging from 70-265 VAC and 90-300 VDC. It also boasts an enhanced front panel, including an RS-232 program port interface with a baud rate of 9600, programmable up to 19200 baud. The well-designed front panel features a large LCD display capable of showing 40 characters, facilitating the user’s viewing of trip or alarm diagnostic messages.

Functional Characteristics:

  1. Integrated Management and Protection: Integrates various protection functions to ensure safe and stable motor operation under various conditions.
  2. Modular Design: Facilitates installation, maintenance, and expansion of other functions.
  3. Multiple Alarm Functions: Detects motor faults promptly and alerts staff for timely handling.
  4. Programmable Control: Meets different motor protection needs, providing flexible configuration options.

Application Fields:
The SR469-P5-HI-A20-E GE motor management relay is suitable for the protection and control of large and medium-sized motors. It is widely used in power, energy, and industrial fields, especially in scenarios requiring high reliability and high-performance motor management.
